| Print Characteristics | |
| Print Method | Direct Thermal |
| Print Speed | Up to 250 mm/sec |
| Print Resolution | 203 dpi |
| Print Width | Up to 32/48/72 mm |
| Sensor | Paper End, Black Mark, Cover Open, Paper Taken |
| Media Characteristics | |
| Media Type | Receipt, Restick |
| Media Width | 80 mm Optional 40/58 mm |
| Media Roll Diameter | Up to 103 mm |
| Media Thickness | 0.06 to 0.09 mm |
| Supply Method | Easy Paper Loading |
| Physical Characteristics | |
| Dimensions (WxLxH) | 144 x 185 x 206 mm (5.67 x 7.28 x 8.11 inch) |
| Weight | 2.20 kg (4.85 lbs.) |
| Electrical | EnergyStar® Certified, External Power Supply Housed Internally (Adapter 24 V/2.5 A) |
| Display | 2 inch Color TFT LCD |
| Drawer Port | 2 ports (Via Y-Type Adapter) |
| Performance Characteristics | |
| Memory | 512 MB SDRAM, 256 MB Flash |
| NV Image Memory | 1024 Kbytes |
| Receive Buffer | 4 Kbytes |
| User Define Buffer | 12 Kbytes |
| Interface | Standard: USB 2.0 HS + Ethernet Optional: ① Standard + Bluetooth® ② Standard + WLAN ③ Standard + Powered USB ④ Standard + Serial ------------------------------------------------ WLAN: 802.11a/b/g/n (Infrastructure, Ad-hoc, Wi-Fi Direct, SoftAP) - WEP40/104, WPA1/2 (PSK, EAP) |
| Environment Characteristics | |
| Temperature | Operating: 0 to 40℃ (32 to 104℉) Storage: -20 to 60℃ (-4 to 140℉) |
| Humidity | Operating: 10 to 80% RH Storage: 10 to 90% RH |
| Sealing | IP22 |
| Reliability | |
| Thermal Print Head (TPH) | Reciept: 150 km Sticky, Restick: 75 Km |
| Auto Cutter | Reciept: 3 Million Cuts Sticky, Restick: 1 Million Cuts |
| * Specified Paper | Iconex Sticky Media (USA): Classic: 9023-1253, 9023-1232 (80 mm), 9023-1823, 9023-1397 (58 mm), 9023-1233, 9023-1818 (40 mm) Classic High Tack: 9023-1254 (80 mm), 9023-1500 (58 mm), 9023-1258 (40 mm) Classic High Temp: 9023-1267, 9023-1463 (80 mm), 9023-1269 (40 mm) Ultralite: 9023-1866 (80 mm), 9023-1410 (58 mm), 9023-1865 (40 mm) Classic High Tack Plus: 9023-1846 (80 mm) - Iconex Linerless Label (USA) Linerless Extreme: 9023-1873, 9023-1708 (40 mm) - MAX International Converters, Inc. MAXStick Products Ltd (USA) |
| Software | |
| Emulation | BXL/POS™ |
| Driver/Utility | Windows® Driver OPOS/JPOS Driver Linux/Mac® CUPS Driver Virtual COM USB/Ethernet Driver Utility Program Network Auto Installer |
| Developer Tools | Android™/iOS®/Windows SDK Linux SDK Xamarin SDK Web Print SDK Cordova Plugin MAUI SDK Flutter™ Plugin React Native SDK B-gate SDK_Cloud Server Print B-gate SDK_Web App Print |
| Design & Print | mPrint App (Android, iOS) |
| MDM (Optional) | BIXOLON Profile Manager - XPM™, XCM™ (Windows, Android) |
| Fonts/Graphics/Symbologies | |
| Character Size | Font A: 12 x 24, Font B: 9 x 17, Font C: 9 x 24, KOR, CHN, JPN: 24 x 24 |
| Characters per Line | Font A: 48, Font B, C: 64 |
| Character Sets | Alphanumeric: 95 Extended Graphics: 128 x 33 page International: 32 |
| Barcode Symbologies | 1D: Coda Bar, Code 39, Code 93, Code 128, EAN-8, EAN-13, ITF, UPC-A, UPC-E 2D: Data Matrix, GS1-128, GS1 DataBar Stacked/ Omnidirectional/ Truncated/ Limited/ Expanded, PDF417, QR code |
| Accessories/ Supplies | |
| Included in the Box | Power Cord, USB A-B Cable 1.8 m |
| Options & Accessories | External Buzzer, B-Melodist, Powered USB (0.5/1.2 m), Serial Cable (9-9/25-9 pin), |
| Compatible Supplies | B-linerless™ |
| Warranty | 2 years |
