Overview

The SPP-L410 4-inch (112mm) Mobile Label Printer is a compact and durable printer with accompanying competitive price point is ideal for label printing applications within the Retail, Warehousing, Manufacturing and Logistics markets.

Sporting an ergonomic, lightweight design weighing just 530g, supporting 112mm and 105mm media widths and media roll diameter up to 56mm. The SPP-L410 produces 203dpi high resolution user defined fonts, graphics, and logos at speeds up to 4ips (102mm/sec) with a memory capacity up to 256 MB SDRAM, 512 MB Flash. Complete with a 7.4 V Li-ion, 2,750 mAh rechargeable battery with a 24 hour battery life once fully charged.  The mobile label device also supports Linerless Labelling printing associated B-linerless media, alongside IP54 dust protection, a splash proof design and 1.8m (6ft.) drop test reliability.

Supporting WLAN Dual band (5 GHz and 2.4 GHz), Bluetooth V4.1 Classic & LE, USB & Serial interface options and Easy Bluetooth Pairing™ via an embedded NFC tag. The SPP-L410 is compatible with all major operating systems including Android™, iOS™, Windows®, Linux with additional Apple MFi iAP2 certification, supported by comprehensive Chrome and Xamarin SDKs. Working with market-leading programming languages including SLCS, BPL-Z™ & BPL-C™ to allow for easy printer integration into a range of installations. The mobile label printer provides label editing capabilities through BIXOLON’s Label Artist-II™, Label Artist™ Mobile (iOS™ and Android™), plus compatibility with Bartender®. While supporting the mPrint App (iOS™ and Android™), and Windows mPrint Browser.

Interface options:

  1. USB V2.0 HS + Serial
  2. USB V2.0 HS + Serial + Bluetooth¹/WLAN²

Bluetooth¹: V4.1 Classic & LE
WLAN²: 802.11a/b/g/n (Infrastructure, Ad-hoc,
Wi-Fi Direct, SoftAP) – WEP40/104,
WPA1/2(PSK, EAP)
* Easy Bluetooth Pairing™ via NFC


Features

  • 4” (112mm) durable 530g mobile label printer printing at speeds up to 4ips (102mm/second) Label and 3ips (76mm/sec) Linerless at 203dpi high print resolution
  • Supporting 112 mm (fixed) and 105 mm (optional) media width
  • Supporting high capacity up to 256 MB SDRAM, 512 MB Flash memory
  • Interface options - Standard: USB V2.0 HS + Serial Optional: USB V2.0 HS + Serial + Bluetooth/ WLAN- compatible with compatible with Apple iOS™, Android™ Symbian™ Linux & Windows™ operating systems with additional Apple MFi iAP2 certification
  • Supported by comprehensive Chrome and Xamarin SDKs
  • Fully compatible with market-leading programming languages - SLCS, BPL-Z™ & BPL-C™
  • Interchange programming language without setting the mode
  • Supporting Easy Bluetooth Pairing™ via embedded NFC tag enabling auto pairing
  • Compatible with label editing software including BIXOLON’s Label Artist-II™, Label Artist™ Mobile (iOS™ and Android™), and Bartender
  • Supporting the mPrint App (iOS™ and Android™), and Windows mPrint Browser
  • Equipped with a Transmissive Gap sensor, Black Mark Reflective sensor and Paper Cover Open Sensor
  • Splash and dust resistant rating of IP54 with 1.8 metre drop ability
  • Long-lasting battery life (24-hour stand by time) once fully charged - Bluetooth model in power save mode
  • One touch cover open and easy paper loading
  • Available in traditional BIXOLON Black
  • Energy Star Certified
  • 2 year warranty as standard (battery 6 months)

Specifications

Print Method Direct Thermal
Print Speed Up to 4 ips (102 mm/sec - Label) Up to 3 ips (76 mm/sec - Linerless) 12.5% pattern
Print Resolution 203 dpi
Print Width Up to 104 mm
Sensor Gap Black Mark Paper Cover Open
Media Type Label, Linerless (Optional)
Media Width 112 mm (Fixed) / 105 mm (Optional)
Media Roll Diameter Up to 56 mm
Media Thickness 0.07 ~ 0.15 mm
Supply Method Easy Paper Loading
Dimensions (WxLxD) 143.0 x 138 x 66 mm (5.63 x 5.44 x 2.60 inch)
Weight Including battery: 530 g (1.17 Ibs.) Paper : 242 g (0.53 lbs.)
Battery 7.4 V Li-ion, 2,750 mAh, Rechargeable Charging time: Up to 4.0 hrs
Memory 128 MB SDRAM, 256 MB Flash 256 MB SDRAM, 512 MB Flash (Optional)
Interface Options Standard: USB V2.0 HS + Serial Optional: USB V2.0 HS + Serial + Bluetooth¹ / WLAN² ----------------------------------------------------------------- Bluetooth¹: V4.1 Classic & LE WLAN²: 802.11a/b/g/n (Infrastructure, Ad-hoc, Wi-Fi Direct, SoftAP) - WEP40/104, WPA1/2(PSK, EAP) * Easy Bluetooth Pairing™ via NFC
Emulation SLCS, BPL-Z™, BPL-C™
Driver / Utility • Windows Driver (Europlus/Seagull) • Linux / Mac CUPS Driver • Virtual COM USB Driver • Utility Program • LabelArtist™ Mobile(Android,iOS) • LabelArtist™-II • Bartender UL • OPOS Driver
SDK / Plugin • Android/iOS/Windows SDK • Linux SDK • Chrome SDK • Xamarin SDK (Windows,Android only)
Browser • Windows mPrint Browser (All) • LabelArtist™ Mobile (Android,iOS) • mPrint App (Android, iOS)
Temperature Operating: -15 ~ 50℃ (5 ~ 122℉) Storage: -30 ~ 70℃ (-22 ~ 158℉)
Humidity Operating: 10 ~ 80% RH
Water and Dust IP54
Drop Rate 1.8 m (6 ft.)
Fonts 10 SLCS / One SLCS / 16 BPL-Z™ / One BPL-Z™ / 7 BPL-C™ / 23 Code Page / Unicode supported (UTF-8, UTF-16LE, UTF-16BE)
Graphics Supporting user-defined fonts, graphics, formats, layouts and logos
Barcode 1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5, UPC/EAN extensions, UPC-A, UPC-E, IMB 2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code,TLC 39
Accessories Standard Belt Clip, Battery Pack, Battery Charger, Power Cord
Accessories Optional Belt Strap, Shoulder Strap, Single Battery Cradle, Quad Battery Charger, Vehicle Charger, Serial/USB Cable, Cleaning Pen, Vehicle Holder, Case
Supplies B-linerlessTM : BIXOLON's flexible and ecological linerless label consumables
