SPP-L3000

Industrial and Powerful

The SPP-L3000 is a compact, 3″ (80 mm) premium level Auto-ID Mobile Label Printer supporting high quality connectivity and labelling. Ideal for a range of applications including supply chain labelling, retail tags, delivery invoicing and more due to its rugged & lightweight design with an easy-to-open peeler and LCD display.

Providing premium-level performance, the SPP-L3000 delivers seamless wireless connectivity with WLAN Dual band (5 GHz and 2.4 GHz), Bluetooth V4.1 Classic and LE support. Appropriate for use with all major operating systems including Android™, iOS™ and Windows® with the use of BIXOLON’s sophisticated SDKs (Software Development Kits) to provide continuous printing capabilities for Tablets, Smartphones or PDAs.

The SPP-L3000 as a number of key features including is compatibility with all marketing-leading languages including BPL-Z™ & BPL-C™. Smart Media Detection™ and Anywhere Anyfont™ (Unicode) removing the need to write multiple code pages for every language. Supporting label design software including BIXOLON’s Label Artist™ (Design bundle program), Label Artist™ Mobile (for iOS and Android) and Seagull’s BarTender® UltraLite for BIXOLON.

The SPP-L3000 is a light weight (694g) robust printer drop tested on concrete from 2.1m / 7Ft. with an IP54 protection rating. Fast processing provides print speeds of up to 127mm/sec producing 203dpi high quality, text graphics, barcodes and QR codes. Supporting a media roll diameter up to 66mm and adjustable paper guide between 25~ 80 mm and featuring a peeler and LCD display (200 x 100 pixels). The SPP-L3000 comes with a high-capacity, rechargeable 7.4 V Li-ion, 2,600 mAh battery capable of providing a 70 hour standby time once fully charged (Bluetooth model in power save mode). The printer is accompanied by a wide range of carrying and charging accessories and comes with a 2 year warranty as standard (battery 6 months only).


Features

Premium-Level Performance

– Fully compatible with market-leading
programming languages
– Interchange programming language without
setting the mode
– Fast data processing and printing speed up to
5 ips (127 mm/sec)
– Smart Media Detection™
– Anywhere Anyfont™ (Unicode) removes the need
to write multiple code pages for every language

Seamless Mobility

– Simultaneously connects both Bluetooth 4.1 (MFi certified) and Dual-band WLAN (2.4GHz and 5GHz)
– Compatible with all major operating systems
including Android™, iOS™ and Windows®
– Supports Easy Bluetooth Pairing™ via
embedded NFC tag enabling auto pairing
– SoftAP – Simple Wi-Fi set up to a
mobile device
– Smart Connection™ mobile app – Easy
switching from SoftAP to Infrastructure mode

Enhanced optimization for field service

– Compact, ergonomic and light-weight (694g)
– 2.1 m / 7 ft. drop rate
– IP54 (Printer only) water and dust proof
– Various accessories and connectivity ports
– Easy to set up the printer status by LCD and
control button
– Visual battery status
– Embedded peeler and paper guide

Specifications

Print Characteristics
Print Method Direct Thermal
Print Speed Up to 5 ips (127 mm/sec - Label, Linerless)
Print Resolution 203 dpi
Print Width Up to 72 mm
Sensing "Paper EndGapBlack MarkPaper Cover OpenPeel-off"
Media Characteristics
Media Type Label, Linerless (Optional)
Media Width 25 ~ 80 mm
Media Roll Diameter Up to 66 mm
Media Thickness 0.07 ~ 0.15 mm
Media Inner Core 19mm, 12mm
Supply Method Easy Paper Loading
Physical Characteristics
"Dimensions(WxDxH)" "119 x 159 x 79 mm (4.67 x 6.26 x 3.12 inch)"
Weight "Including battery: 694 g (1.53 Ibs.) Paper : 257 g (0.57 lbs.)"
Electrical "7.3 V Li-ion, 2850 mAh (Nominal), RechargeableCharging time: Up to 2.5 hrsEnergyStar Certified"
Peeler Supported
Paper guide Yes (Inner core: 19mm)
Display FSTN LCD (200 x 100 pixels)
Performance Characteristics
Memory "128 MB SDRAM, 256 MB Flash 256 MB SDRAM, 512 MB Flash (Optional)"
Interface "Standard: USB V2.0 HS + Serial Optional: USB V2.0 HS + Serial + Bluetooth / WLAN / Dual (Bluetooth + WLAN)-----------------------------------------Bluetooth: V4.1 Classic & LEWLAN: 802.11a/b/g/n (Infrastructure, Ad-hoc, Wi-Fi Direct, SoftAP) - WEP40/104, WPA1/2 (PSK, EAP) -----------------------------------------Easy Bluetooth Pairing™ via NFC"
Environment Characteristics
Temperature "Operating: -15 ~ 50℃ (5 ~ ~ 122℉)Storage: -30 ~ 70℃ (-22 ~ 158℉)"
Humidity Operating: 10 ~ 80% RH
Sealing IP54
Drop Rate 2.1 m (7 ft.)
Software
Emulation SLCS, BPL-Z™ (ZPLII), BPL-C™ (CPCL)
Driver/Utility "Windows Driver (Europlus/Seagull)Linux / Mac CUPS DriverVirtual COM USB DriverUtility ProgramLabelArtist-II™Bartender ULOPOS/JPOS DriverSAP® Device Driver"
SDK/Plugin "Android/iOS/Windows SDKLinux SDKChrome SDKXamarin SDKCordova Plugin"
Application "Label Artist™Mobile (Android,iOS)mPrint App (iOS)mPrint Server (Windows, iOS)"
MDM(Optional) BIXOLON Profile Manager - XPM™, XCM™ (Windows, Android)
Fonts/Graphics/Symbologies
Fonts 10 SLCS / One SLCS / 16 BPL-Z™ / One BPL-Z™ / 7 BPL-C™ / 23 Code Page / Unicode supported (UTF-8, UTF-16LE, UTF-16BE)
Graphics Supporting user-defined fonts, graphics, formats, layouts and logos
Barcode Symbologies "1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8,Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5, UPC/EAN extensions, UPC-A, UPC-E, IMB2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39"
Accessories
Standard "Belt Strap, Battery Pack, SMPS,Power Cord, Paper Disk (Inner core : 12mm)"
Optional Shoulder Strap, Single Battery Charger, Quad Battery Charger, Serial/USB Cable, Fixed Serial/USB Cable, Ram mount Vehicle-Holder, Vehicle Charger
Integrated Card Reader (Optional)
MSR
SCR
Supplies
B-linerless™ : BIXOLON's flexible and ecological linerless label consumables

Industries

Industry Transport and Logistics

Public Transporation
Logistics

Healthcare

Pharmacy & Lab

Retail

Instore Operations
Supply Chain

Government

Postal/Courier
Administration

Manufacturing

Field Operations
Plant Operations
